The TS-h1090FU high-density NVMe all-flash storage is designed for providing extreme performance with high cost-efficiency. Featuring ten U.2 NVMe Gen 4 x4 SSD bays, the TS-h1090FU delivers remarkable random read/write IOPS with ultra-low latency. The ZFS-based QuTS hero operating system supports inline data deduplication and compression for reducing I/O and SSD storage consumption, which significantly extends SSD lifespan with a higher price-performance ratio for all-flash storage arrays. Ideal for I/O-intensive and latency-sensitive applications, the TS-h1090FU eliminates productivity bottlenecks in virtualization, modern data centers, multimedia storage, and mission-critical backup/restore tasks-suitable for Tier 2 storage workloads with an ideal low cost-per-GB.
-
Optimized SSD performance and lifespan
Inline data deduplication and compression, Pool Over-provisioning, and TRIM maximize SSD performance and lifespan.
-
25GbE future-proof connectivity
Accelerates virtualization, intensive file access, media transfer, and large backup/restoration tasks.
-
High-speed PCIe Gen 4 slots
Allows installing 10/25/40/100GbE adapters, QM2 cards, or Fibre Channel cards to increase application performance.
-
Virtualization applications
Supports virtualization storage, virtual machines with SR-IOV support, and containerized apps.
CPU |
AMD EPYC™ 7302P 16-core/32-thread processor, up to 3.3 GHz |
CPU Architecture |
64-bit x86 |
Encryption Engine |
(AES-NI) |
System Memory |
256 GB RDIMM DDR4 ECC (8 x 32 GB) |
Maximum Memory |
1 TB+ (12 x 128 GB) |
Memory Slot |
12 x RDIMM DDR4 |
Flash Memory |
5GB (Dual boot OS protection) |
Drive Bay |
10 x 2.5-inch U.2 PCIe NVMe / SATA 6Gbps The system is shipped without SSD. |
Drive Compatibility |
2.5-inch U.2 NVMe Gen 4 x4 solid state drives
2.5-inch SATA solid state drives |
Hot-swappable |
|
SSD Cache Acceleration Support |
|
SR-IOV |
|
2.5 Gigabit Ethernet Port (2.5G/1G/100M) |
2 (2.5G/1G/100M/10M) |
25 Gigabit Ethernet Port |
2 x 25GbE SFP28 SmartNIC port |
Wake on LAN (WOL) |
Only the 2.5GbE port
|
Jumbo Frame |
|
PCIe Slot |
2
Slot 1: PCIe Gen4 x16
Slot 2: PCIe Gen4 x16
For low profile PCIe cards only.
Card dimensions for PCIe slot 1:198 x 68.9 x 18.76 mm / 7.8 x 2.71 x 0.74 inches.
Card dimensions for PCIe slot 2:250 x 68.9x 18.76 mm / 9.84 x 2.71 x 0.74 inches.
Wider cards can be installed if the next PCIe slot will not be used.
|
USB 3.2 Gen 1 port |
3 |
Form Factor |
Rackmount |
LED Indicators |
Disk, Status, LAN, storage expansion port status |
Buttons |
Power, Reset |
Dimensions (HxWxD) |
44 × 430 × 582 mm |
Weight (Net) |
11.6 kg |
Weight (Gross) |
13.4 kg |
Operating Temperature |
0 - 40 °C (32°F - 104°F) |
Storage Temperature |
-20 - 70°C (-4°F - 158°F) |
Relative Humidity |
5-95% RH non-condensing, wet bulb: 27˚C (80.6˚F) |
Power Supply Unit |
550W PSU (x2), AC 100-240 V |
Power Consumption: Operating Mode, Typical |
157.97 W
Tested with drives fully populated.
|
Fan |
5 x 60mm, 12VDC |
System Warning |
Buzzer |
Standard Warranty |
5 |
Max. Number of Concurrent Connections (CIFS) - with Max. Memory |
10,000 |
