Add dual M.2 2280 NVMe PCIe SSDs and a 10 Gigabit Ethernet port to select QNAP NAS, Windows, and Linux devices with the QM2-2P10G1TB Dual M.2 2280 PCIe NVMe SSD & 10GbE Expansion Card from QNAP. By combining M.2 PCIe 3.0 x4 SSD storage and 10GbE connectivity into one solution, the QM2-2P10G1TB helps improve overall system performance by enabling SSD caching, while also providing an affordable upgrade path for adopting 10GbE networks. Its PCIe 3.0 x8 interface also provides higher bandwidth than SATA, which allows for faster computing speed and data access. By default, the QM2-2P10G1TB is mounted to a low-profile bracket, but low-profile flat and full-height brackets are also included.
Please note that M.2 SSDs are not included. Windows requires a driver, which may be downloaded for free from QNAP's site. Also, the TS-x77 and TVS-x82(T) series only supports installing the QM2 in the System Zone PCIe slot (PCIe slot 1).
For NAS
Tackle Performance Bottlenecks
The QM2-2P10G1TB boosts NAS performance by adding M.2 PCIe Gen3 NVMe SSDs. It doesn't occupy any 3.5" drive bays, allowing you to maximize both your storage capacity and performance.
- M.2 SSDs can be installed (no tools required) to form caching pools or an auto-tiering volume.
- Enables SSD caching to boost performance and optimizes storage efficiency with Qtier Technology.
- Provides 10GBASE-T connectivity and backward compatibility with 5GbE/2.5GbE/1GbE/100MbE
- M.2 SSD thermal sensors allow real-time M.2 SSD temperature monitoring.
- A quiet cooling module (heatsink and smart fan) minimizes overheating risks and sustains constant high performance.
- LED indicators enable monitoring of M.2 SSD status.
Future-Proof 10GbE Network Environments
The QM2-2P10G1TB features a 10GBASE-T multi-Gigabit (10G/5G/2.5G/1G/100M) network port to empower your QNAP NAS with 10GbE high-speed connectivity for bandwidth-demanding tasks. With QNAP's various 10GbE switches, you can easily upgrade to a high-speed network environment.
For PC/Server
Enhanced Performance for Demanding Applications
The QM2-2P10G1TB allows for adding M.2 NVMe SSDs to increase the storage capacity of your Windows/Linux PC/workstation while also boosting overall IOPS performance by offloading bandwidth-demanding tasks to the SSDs. It is ideal for tasks such as inline video-editing, gaming, and other applications that require low latency, reduced loading times, and high bandwidth. Highly energy efficient and cost-effective, the QM2-2P10G1TB provides a high-performance storage expansion and 10GbE solution.
Future-Proof 10GbE Network Environments
The QM2-2P10G1TB features a 10GBASE-T multi-Gigabit (10G/5G/2.5G/1G/100M) network port to empower your PC/workstation with 10GbE high-speed connectivity for bandwidth-demanding tasks. With QNAP's various 10GbE switches, you can easily upgrade to a high-speed network environment.
M.2 SSD Thermal Sensors
M.2 SSD thermal sensors allow real-time M.2 SSD temperature monitoring.
Quiet Cooling Module
A quiet cooling module (heatsink and smart fan) minimizes overheating risks to sustain constant high performance.
LED Indicators
LED indicators help with monitoring M.2 SSD status.
Tool-less Installation
Tool-less quick installation and replacement M.2 SSD.
NAS Compatibility
4 Bays
QVP-41A, TS-464, TS-464U, TS-464U-RP, TS-473, TS-473A, TVS-471, TVS-472XT, TVS-473, TVS-473e
6 Bays
QVP-63A, TS-664, TS-673, TS-673A, TS-677, TS-h686, TVS-671, TVS-672N, TVS-672X, TVS-672XT, TVS-673, TVS-673e, TVS-682, TVS-682T
8 Bays
QVP-85A, TS-864eU, TS-864eU-RP, TS-873, TS-873A, TS-873AeU, TS-873AeU-RP, TS-873AU, TS-873AU-RP, TS-873U, TS-873U-RP, TS-877, TS-877XU, TS-877XU-RP, TS-883XU, TS-883XU-RP, TS-EC880 Pro, TS-EC880U, TS-EC880U R2, TS-h886, TVS-871, TVS-871T, TVS-872N, TVS-872X, TVS-872XT, TVS-872XU, TVS-872XU-RP, TVS-873, TVS-873e, TVS-882, TVS-882BR, TVS-882BRT3, TVS-882ST2, TVS-882ST3, TVS-882T, TVS-EC880
9 Bays
TS-977XU, TS-977XU-RP, TS-983XU, TS-983XU-RP, TS-h977XU-RP, TVS-972XU, TVS-972XU-RP
10 Bays
TNS-h1083X, TS-EC1080 Pro, TVS-EC1080, TVS-EC1080+
12 Bays
TS-1264U-RP, TS-1273AU-RP, TS-1273U, TS-1273U-RP, TS-1277, TS-1277XU, TS-1277XU-RP, TS-1283XU-RP, TS-EC1280U, TS-EC1280U R2, TS-h1277XU-RP, TS-h1283XU-RP, TS-h1290FX, TVS-1272XU-RP, TVS-1282, TVS-1282T, TVS-1282T3, TVS-EC1280U-SAS-RP, TVS-EC1280U-SAS-RP R2, TVS-h1288X
15 Bays
TVS-1582TU, TVS-EC1580MU-SAS-RP, TVS-EC1580MU-SAS-RP R2
16 Bays
TS-1673AU-RP, TS-1673UTS-1673U-RP, TS-1677X, TS-1677XU, TS-1677XU-RP, TS-1683XU-RP, TS-1685, TS-EC1680U, TS-EC1680U R2, TS-h1677XU-RP, TS-h1683XU-RP, TVS-1672XU-RP, TVS-EC1680U-SAS-RP, TVS-EC1680U-SAS-RP R2, TVS-h1688X
18 Bays
TES-1885U, TES-1885U(QTS), TS-1886XU-RP, TS-h1886XU-RP, TS-h1886XU-RP R2
24 Bays
TDS-h2489FU, TS-2477XU-RP, TS-2483XU-RP, TS-EC2480U, TS-EC2480U R2, TS-h2477XU-RP, TS-h2483XU-RP, TS-h2490FU, TVS-2472XU-RP, TVS-EC2480U-SAS-RP, TVS-EC2480U-SAS-RP R2
28 Bays
TS-2888X
30 Bays
TES-3085U, TES-3085U(QTS), TS-h3088XU-RP
System Connection |
PCI Express 3.0 x8
|
External I/O |
1x RJ45 (10 GbE)
|
M.2 |
2x M Key 2280 (PCIe 3.0 x4)
|
OS Compatibility |
Windows
Linux
|
General
System Connection |
PCI Express 3.0 x8
|
External I/O |
1x RJ45 (10 GbE)
|
M.2 |
2x M Key 2280 (PCIe 3.0 x4)
|
Controller |
Marvell AQC113C
|
OS Compatibility |
Windows
Linux
|
Physical
Form Factor |
Low Profile
|
Status Monitoring |
LED Indicator
|
Dimensions |
6.01 x 2.71 x 0.74" / 152.65 x 68.83 x 18.8 mm
|
