Sony's PXW-Z190 4K 3-CMOS 1/3" Sensor XDCAM Camcorder continues the fine tradition of the XDCAM series of cameras. It captures 4K at up to 60p, relying on three 1/3" Exmor R sensors that provide improved low-light capability compared to standard sensors. The camera integrates a 25x optical Sony G zoom lens and an electronic variable ND filter. The camera supports a variety of codecs out of the box, with an optional MPEG HD license enabling you to shoot HD video.
The camera supports HLG (Hybrid Log Gamma), allowing you to shoot and deliver footage compatible with both HDR (high dynamic range) and SDR (standard dynamic range) without needing laborious post-production work. Dual SD card slots permit a variety of recording options, including simultaneous HD and 4K recording. The camera features built-in 2.4 and 5 GHz Wi-Fi.
Key Specs
| Sensor Resolution |
Effective: 8.3 Megapixel
|
| Image Sensor |
1/3"-Type 3-Chip CMOS
|
| Internal Recording Modes |
XAVC-L
3840 x 2160 at 23.98/25/29.97/50/59.94 fps [150 Mb/s]
1920 x 1080p at 23.98/25/29.97/50/59.94 fps [35 to 50 Mb/s]
1920 x 1080i at 50/59.94 fps [25 to 50 Mb/s]
1280 x 720 at 50/59.94 fps [50 Mb/s]
DV
720 x 480i at 59.94 fps
720 x 480p at 29.97 fps
720 x 576i at 50 fps
720 x 576p at 25 fps
Show More
|
| Media/Memory Card Slot |
Dual Slot: SD/SDHC/SDXC
|
| Video I/O |
1x BNC (3G-SDI) Output
1x HDMI Output
|
| Battery Type |
Sony BP-U Series
|
Imaging
| Sensor Resolution |
Effective: 8.3 Megapixel
|
| Image Sensor |
1/3"-Type 3-Chip CMOS
|
| Built-In ND Filter |
Mechanical Filter Wheel with Clear, 2-Stop (1/4), 4-Stop (1/16), 6-Stop (1/64) ND Filters and a 2 to 7 Stop Electronic ND Filter
|
| Capture Type |
Video Only
|
Exposure Control
| Shutter Type |
Electronic Rolling Shutter
|
| Shutter Type |
Electronic Rolling Shutter
|
| Shutter Speed |
1/8000 to 1/24 Second
|
| Minimum Illumination |
0.02 Lux
|
Lens
| Focal Length |
3.7 to 92.5mm (35mm Equivalent: 28.8 to 720mm)
|
| Optical Zoom Ratio |
25x
|
| Maximum Aperture |
f/1.6
|
| Minimum Aperture |
f/11
|
| Filter Size |
82 mm
|
| Control Rings |
Focus
Zoom
Iris
|
| Focus Control |
Autofocus
Manual Focus
|
Video Capture
| Internal Recording Modes |
XAVC-L
3840 x 2160 at 23.98/25/29.97/50/59.94 fps [150 Mb/s]
1920 x 1080p at 23.98/25/29.97/50/59.94 fps [35 to 50 Mb/s]
1920 x 1080i at 50/59.94 fps [25 to 50 Mb/s]
1280 x 720 at 50/59.94 fps [50 Mb/s]
DV
720 x 480i at 59.94 fps
720 x 480p at 29.97 fps
720 x 576i at 50 fps
720 x 576p at 25 fps
|
| Built-In Microphone |
Stereo
|
| Audio Recording |
XAVC: 4-Channel 24-Bit 48 kHz LPCM Audio
|
| IP Streaming |
Yes
|
Interface
| Media/Memory Card Slot |
Dual Slot: SD/SDHC/SDXC
|
| Video I/O |
1x BNC (3G-SDI) Output
1x HDMI Output
|
| Audio I/O |
2x XLR 3-Pin Mic/Line (+48 V Phantom Power) Input
1x 1/8" / 3.5 mm TRS Stereo Headphone Output
|
| Other I/O |
1x BNC (Timecode) Input/Output
1x Micro-USB
2x USB-A
1x RJ45 (LAN)
1x 2.5 mm Sub-Mini (LANC) Control
|
| Wireless |
2.4 / 5 GHz Wi-Fi 5 (802.11ac), NFC
|
Monitor
| Display Type |
Articulating LCD
|
| Display Size |
3.5"
|
| Resolution |
1,560,000 Dot
|
Viewfinder
| Type |
Built-In Electronic (LCD)
|
| Size |
0.39"
|
| Resolution |
2,360,000 Dot
|
Focus
| Focus Type |
Auto and Manual Focus
|
| Focus Mode |
Automatic, Manual Focus
|
General
| Battery Type |
Sony BP-U Series
|
| Accessory Mounting Thread |
1 x
|
| Built-In Video Light |
No
|
| Dimensions (W x H x D) |
7.5 x 8 x 16.5" / 190 x 202 x 419.7 mm (With Protrusions)
|
| Weight |
5.07 lb / 2.3 kg
|
